| The hole diameter (mm) | 100-219 |
| Drilling depth (m) | 130 |
| Drill pipe diameter (mm) | φ76, φ89 |
| Drill pipe length(m) | 1.5m, 2.0m |
| One-time stroke (m) | 2.3 |
| Walking speed(km/h) | 3 |
| Climbing angles(Max.) | 30 |
| Air pressure(MPA) | 1.45-2.5 |
| Air consumption (m3 /min) | 15-29 |
| Rotating speed(rpm) | 40-65 |
| Rig lifting force(T) | 6 |
| Rapid rise speed(m/min) | 15 |
| Fast feeding speed(m/min) | 23 |
| High leg stroke(m) | 0.6 |
| The feeding efficiency(m/h) | 10-35 |
| Diesel engine Brand | Changchai |
| Power(HP) | 32 |
| Rotating torque(N.m) | 2200-3000 |
| Dimension(mm) | 3850x1560x2050 |
| The weight (T) | 3 |
