Main Application
◆Drilling wells for urban and rural life
◆Drilling wells for agricultural irrigation and industries
◆Drilling for geotechnical survey
◆Drilling construction engineering holes
◆Drilling geothermal pump wells
Main specification
| Drilling Parameter | |
| Hole diameter： | 90--1200(mm) |
| Hole depth： | 250(m) |
| Run Of Rod： | 3、4(m) |
| Drill rod diameter： | φ60 φ73 φ89 φ95 φ133(mm) |
| Drilling Technology： | Normaland Reverse Circulation for both Mud and Air |
| Down-The-Hole hammers: | Middle-High-Pressure Air |
| Performance parameter | |
| Drill Head Inside Diameter： | φ60 φ80 φ120 |
| Drill Head lifting speed(m/s)： | 0.37 0.16 |
| Drill Head lifting Force(kN)： | 45.4 105 |
| Drill Head Spin Speed: | A(Forward:14-23-52-84,Reverse:8-13-29-47r/min） |
| B(Forward:32-52-116-188,Reverse:18-29-65-106r/min） | |
| Shape Parameters | |
| Dimensions： | （L-W-H) Working conditions 7900×2370×7200(mm) |
| Transport status: | （L-W-H) 8450×2370×3400(mm) |
| Supporting Form： | Hydraulic Unit |
| Mast Up-Down： | Hydraulic Unit |
| Rig mass： | 9100(Kg) |
| Chassis： | Dong Feng EQ1093 (four-wheel drive) |
| Power Unit： | Diesel Engine |
| Power： | 42(kW) |
| Pump： | BW450 Mud Pump |
| Flow(L/min)： | 450 |
| Pressure(Mpa) | 1.2 |
| Main Hoist Lifting Force： | 20.6(kN) |
| Feed Thrust： | 0-15（kN） |
| Notes: Drill head spin speed can be selected, A is normal | |
