| Model | 550RH | 600XH | 750H | 600RH | 750XH | 825XH | 900HH | 900H | 1050 | 980XH | 1070RH | 1070XHH | 1250XH |
|
Nominal volume fand /min (CFM) |
15.5 (550) |
17 (600) |
21.2 (750) |
17 (600) |
21.2 (750) |
23.4 (825) |
25.5 (900) |
25.5 (900) |
29.7 (1050) |
27.8 (980) |
30.3 (1070) |
30.3 (1070) |
35.4 (1250) |
|
Rated discharge pressure bar (PSI) |
17 (250) |
13.8 (600) |
10 (150) |
17 (250) |
13.8 (200) |
13.8 (200) |
12 (175) |
10.3 (150) |
8.6 (125) |
24. 1(350) |
20. 7(300) |
34. 5(500) |
24.1 (350) |
|
Working pressure range bar |
6.5- 17 |
3.5-13.8 | 3.5-10 |
6.5- 17 |
5.5-13.8 (80-200) |
5.5-13.8 (80-200) |
5.5-12 (80-175) |
5.5-10.3 (80-150) |
5.5-8.6 (80-125) |
9.7-24.1 | 9.7-20.7 | 13.8-34.5 | 13.8-24.1 |
|
Maximum traction speed km/h |
35 | ||||||||||||
| Noiselevel(soundpressure) at 7m distance | 79 | 80+/-3 | |||||||||||
| Total weight of unit kg | 3200 | 4880(10759) | 6535 | 7300 | |||||||||
| Outer dimension Long * wide * high mm |
4210*2150*2050（to shed top） |
4090*2100*2470 |
4687*2100 *2396 |
4687*2100 *2558 |
4680*2100*2490 |
||||||||
|
4510*2150*2170（total unit height） |
|||||||||||||
| Tire specifications | 7.5-16-14PR | 7.50-16-14PR | 8.25-16-14PR | 8.25-16-14PR | |||||||||
| Tire pressure kPa (PSI) | 690-760(100-110) | 630-690(91-100) | 690-760(100-110) | 690-760(100-110) | |||||||||
| Maximum operating altitude -m | 3048 | 4876(16,000) | |||||||||||
| Diesel engine | |||||||||||||
| Manufacturer | Dongfeng CUMMINS | CUMMINS |
CATERPILLAR (ACERT) |
CATERPILLAR (ACERT) |
|||||||||
| Model | 6CTA8.3-C240 | 6CTA8.3-C260 | QSM11-290 | C13 | C15ACERT Tier3 | ||||||||
| Full load / no-load speed rpm | 1800/1300 | 1850/1300 | 1800/1200 | 1800/1300 | 1800/1300 | ||||||||
| Rated power BHP (KW) | 240(179) | 260(194) | 216(290) | 328(440) | 403(540) | ||||||||
| Displacement L (M fand) | 8.3(506) | 10.8(660) | 12.5(762.8) | 15.2(927.6) | |||||||||
| Water tank capacity L (U.S.gal) | 22(5.8) | 40(10.6) | 57(15) | 60(15.9) | |||||||||
| Oil capacity L (U.S.gal) | 18(4.8) | 34(9) | 40.3(10.6) | 40.3(10.6) | |||||||||
| Fuel tank capacity L (U.S.gal) | 375(99) | 460(121.5) | 700(185) | 700(185) | |||||||||
| Working voltage of electrical system V | 24 | 24 | 24 | 24 | |||||||||
| Battery rated capacity | 210Ah/ea | 210Ah | 210Ah/ea | 210Ah/ea | |||||||||
| Compressor | |||||||||||||
| Gas supply valve specifications | Rp2*1,Rp3/4*1 | Rp2*1,Rp3/4*1 | |||||||||||
| Lubricating oil capacity L (U.S.gal) | 26(6.8) | 60(15.8) | 60(15.8) | 60(15.8) | |||||||||
